Kersten KM 10037 H-FKDR Sweeper for Ride-On Mowers: Compact and Efficient Cleaning Solution
The Kersten KM 10037 H-FKDR is a hydraulically driven 100 cm front sweeper built for superior cleaning on hard and artificial surfaces. Its FKDR linkage compatibility allows quick attachment changes in seconds, enhancing versatility and reducing downtime. The integrated control panel ensures precise adjustments for oil flow, lifting, lowering, and swiveling, making it a reliable and efficient choice for professional maintenance.
Built with robust, CNC-folded heavy-gauge steel, the KM 10037 H-FKDR delivers durability and reliability. Its inboard variable-speed hydraulic drive motor and constant-tension duplex drive chain provide powerful, slip-free brush operation. The pendulum suspension system ensures smooth performance over rough terrain by protecting both the sweeper and carrier. Featuring a Ø 37 cm five-row combi brush, this sweeper handles large, heavy debris with ease, while individually adjustable gauge wheels ensure precise brush height positioning. Suitable for a wide range of ride-on mowers, it is the ideal solution for efficient grounds maintenance.
100 cm
37 cm
30°
51 kg
Technical Specifications
| Machine Specification | Details |
|---|---|
| Overall Machine Width | 108 cm |
| Overall Machine Length | 40 cm |
| Machine Height | 44 cm |
| Working Width | 100 cm |
| Brush Diameter | 37 cm |
| Swivel Angle | 30° (Hydraulic Adjustment) |
| Weight | 51 kg |
| Height Adjustment | 2 Heavy-Duty Running Wheels (135 x 40 mm) |
| Front Linkage Features | Quick coupling, integrated lift, and speed adjustment |
| Mounting | FKDR-HYDR Front Linkage Kit |
| Optional Attachments | Gully Brushes, Collector Box, Front Brush Guard and Parking Support |
Features
- Powered by an integrated hydraulic system with stepless speed adjustment for precise control.
- Including 5 row poly sweeper brush ensures effective debris removal on hard and artificial surfaces.
- Compact, robust steel frame for long-lasting performance in demanding environments.
- Two heavy-duty 135 x 40 mm wheels allow easy adjustment for optimal brush positioning.
- Hydraulic control enables 30° left and right swivel and lifting and lowering directly from the driver’s seat for maneuverability.
- Optional Accessories: Gully brushes, front brush guard, collector box and Parking support for storage.
Mounting Bracket Required: FKDR-HYDR
.png)
Optional Accessories
Consumables
9b2620.jpg)
*Required* Compatible FKDR Front linkage
FKDR Sweepers are compatible with the front linkage models listed below. For vehicles with similar specifications, consider FKM37 sweeper.
Product Applications
Sweeping on Hard Surfaces
When organic debris covers a hard surface it looks unsightly, but it also blocks drainage channels, which leads to surface water. Over time the material will decompose producing soil. Opportunistic weeds can use this soil as a platform to grow on the surface, which can cause damage over time. So it is really important to keep the surface swept and to remove the material.
Sweeping on Artificial Surfaces
In addition to the normal problems we face maintaining hard surfaces; artificial surfaces have infill, which gets compacted and also migrates around the surface. This infill can be de-compacted with a sweeper allowing the surface to drain properly. The sweeper will also even out the distribution of infill and stand up the grass, making the surface much nicer to use.
