Product Overview
100cm Mechanical PTO Driven De-moss Front Sweeping Machine suitable for UBS Hydro 9/13/16 Pedestrian Two Wheel Tractor
The EFKM 100 DE-MOSS is a 100cm Mechanical PTO Driven front sweeping machine, compatible with UBS Hydro 9/13/16 pedestrian tractors. Featuring a 37 cm brush diameter and a 30-degree swivel angle, it offers a working width of 100 cm and 122 cm with gully brush. The Sweeper bristle is made with patened nylon; ideal for efficient weed and moss removal on hard surfaces like tarmac and concrete adn artificial surfaces such as tennis court, this machine delivers reliable performance for road sweeping, snow sweeping, and light moss removal.
100 cm; 122cm(with gully brush)
37 cm
30°
52 kg
Technical Details
| Machine Specification | EFKM 100 DE-MOSS |
|---|---|
| Overall Machine Width (cm) | 108 |
| Overall Machine Length (cm) | 63 |
| Overall Height (cm) | 54 |
| Weight (kg) | 52 |
| Brush Diameter (cm) | 37 cm |
| Swivel Angle (degrees) | 30 |
| Working Width (cm) | 100 |
| Working Width with Side Broom (cm) | 122 |
- Quick change K70 attachments system requires no tools.
- Direct drive hydraulic transmission with quick-release couplings.
- Side, inboard-mounted hydraulic motor to reduce overall working width.
- Finely adjustable brush height with 2 heavy-duty caster wheels.
- Simple angling adjustments: Left, centre, right.
- Pivots at centre to follow surface contours.
- Fitted with standard 5-row spiral poly brush.
- Low vibration: 2.86 m/s².
Accessories for the EFKM100 DE-MOSS Sweeper
 small.jpg)
.jpg)
Consumables for the EFKM100 DE-MOSS Sweeper
Compatible with these power unit
.jpg)
 400.jpg)
Applications
Moss & Weed Control
When Moss and Weeds become established on hard surfaces, such as block paving; tarmac; or concrete - they are difficult to remove with a sweeper. For this application we have made the Sweeper. Kersten sweeper have been designed to quickly remove weeds and moss.
Artificial Surface Maintenance
In addition to the normal problems we face maintaining hard surfaces; artificial surfaces have infill, which gets compacted and also migrates around the surface. This infill can be de-compacted with a sweeper allowing the surface to drain properly. The sweeper will also even out the distribution of infill and stand up the grass, making the surface much nicer to use.
Articles about Kersten Sweepers
Maintaining a Polymeric sports surface
Cleaning and maintaining a Polymeric rubber crumb surface like a running track or tenni...
Maintaining synthetic sports surfaces with Kersten sweepers
How can a Kersten machine help to maintain artificial surfaces?
Cleaning of slipways and harbour infrastructure
The use of chemicals to clean algae and other deposits off slipways and marine structur...
SWEEPING hard surfaces as an effective weed control solution.
Sweeping a surface can be used as part of an effective preventative weed control strate...
