SW 85 - Powered Sweeper

Item Code: SW 85

The SW85 is a dedicated sweeper for surface maintenance in areas such as schools, caravan parks and other small sites. The hydraulic drive to the wheels makes it easy to operate and the optional collector and gully brush help leave a great finish.

SW85 Intro
Vibration
Slope
Power
Hyd Flow

2.86m/s

15o

4.5hp

9l/m

UOM : Piece


Product Overview


Specifications


  • 5.5 hp Honda petrol engine
  • Hydraulic transmission
  • Forward direction only with differential 0-4km/h
  • Large diameter drive wheels (4.00-8 turf pattern)
  • Handlebar with 3 height adjustments
  • 82cm Sweeper with 5 row combi-brush
  • Axle load - 300kg
  • W 60cm - L 175cm - H 115cm
  • Noise - less than 84dB
  • low vibration - 2.86m/s2


Description


The SW85 is a dedicated sweeper for general surface maintenance in areas such as schools, caravan parks and other small sites. The hydraulic drive to the wheels makes it eas to operate when removing denser material.

Operating the machine is as simple as two levers, the right hand controls the operation of the brush, while the operator controls the forward speed by varying the position of the left hand lever.

The 5 row nylon brush is formed in a spiral, this allows bulky material to be moved more easily with less power than other systems, leaving a much cleaner finish.

(This product is a standard bundle of ourK820 power unitwith anEFKM 82cm sweeperfitted.)


Customer Stories


Martin Roberts of CIT Group


"The court remained wet for prolonged periods of time which meant that it was slippery, played too fast and the ball tended to skid off the surface." explained Martin
"I have to say that one day's use of the Kersten machine has had a profound effect on the court and it already looks in great shape."


Design Features


Hydraulic Drive

Adjustable Handlebars

Spiral Brush



Fwd Variable Speed

Gully Brush

Large Dia. Wheels



Collector Box

Adjustable Brush Height

Brush Angling
